Rigid 4.75 Ton Short Jib Attachment In Stock Melbourne
The EW-RJS475 is designed as an affordable general purpose jib able to manoeuvre in confined spaces, with a 2.0 metre reach when fully extended. Simply slide onto the Fork Tines and secure with safety chain. The standard finish on this unit is Hot Dip Galvanized Finish. Supplied with Hook and Shackle. In Stock Melbourne.
- *
Rigid 4.75 Ton Short Jib Attachment In Stock Melbourne
The EW-RJS475 is designed as an affordable general purpose jib able to manoeuvre in confined spaces, with a 2.0 metre reach when fully extended. Simply slide onto the Fork Tines and secure with safety chain. The standard finish on this unit is Hot Dip Galvanized Finish. Supplied with Hook and Shackle.
- Safe Working Load (SWL 4750kg Max)
- Unit weight 130kg
- Pocket size 185 x 75 mm
- Pocket centres 275 mm
- Horizontal Centre of Gravity 780mm
- Vertical Centre of Gravity 165mm
- Load Centre 780mm
Safe Working Load Per Position
| POSITION | 1 | 2 | 3 | 4 |
| EXTENSION (mm) | 780 | 1200 | 1580 | 1960 |
| SWL (Kg) | 4750 | 2400 | 1800 | 1500 |
In Stock Melbourne, Australia.
